21 HYBRID RESTORATIONS WITH THE CAMLOG ® IMPLANT SYSTEM INTRODUCTION In implantological hybrid prosthetics, bar restorations represent stable im- plant-connecting designs; a hybrid prosthesis can be securely anchored. TASKS OF A BAR RESTORATION • Protecting the prosthesis against shearing and lifting forces • Shear distribution • Stabilization and primary splinting of the implants • Resilience compensation through degrees of freedom The CAMLOG ® bar abutment offers extensive options for fabrication of prefabricated and custom-milled bars because of the wide variety of com- ponents available: PREFABRICATED TITANIUM OR GOLD BAR Laser-welded bar version with prefabricated titanium bar bases and bar elements or soldered bar version with prefabricated gold bar bases and bar elements. CUSTOM-CAST/MILLED BAR Cast bar version with prefabricated bar bases and bar elements made of burn-out plastic for solid casting technology. BONDED BAR CONSTRUCTION (PASSIVE FIT) Bonded bar construction with prefabricated bar sleeves made of burn-out plastic for casting technology and titanium bonding base. The Passive Fit System provides the option of fixing cast bars on the implants that are absolutely tension-free. PRODUCT DESCRIPTION CAMLOG ® bar abutments are available for all CAMLOG ® implant diameters in various gingival heights. BAR RESTORATIONS CAMLOG ® BAR ABUTMENT FOR IMPLANT DIAMETER 3.3 MM ART. NO. J2255.3305 J2255.3320 GH 0.5 mm 2.0 mm CAMLOG ® BAR ABUTMENT FOR IMPLANT DIAMETER 3.8 MM ART. NO. J2255.3805 J2255.3820 J2255.3840 GH 0.5 mm 2.0 mm 4.0 mm CAMLOG ® BAR ABUTMENT FOR IMPLANT DIAMETER 4.3 MM ART. NO. J2255.4305 J2255.4320 J2255.4340 GH 0.5 mm 2.0 mm 4.0 mm CAMLOG ® BAR ABUTMENT FOR IMPLANT DIAMETER 5.0 MM ART. NO. J2255.5005 J2255.5020 J2255.5040 GH 0.5 mm 2.0 mm 4.0 mm CAMLOG ® BAR ABUTMENT FOR IMPLANT DIAMETER 6.0 MM ART. NO. J2255.6005 J2255.6020 J2255.6040 GH 0.5 mm 2.0 mm 4.0 mm GH: Gingival height
