CAMLOG
®
Product catalog 2017
SCREW-LINE –
GUIDE SYSTEM
Article
Art.-No.
L
A
Guide System CAMLOG
®
SCREW-LINE Implant,
Promote
®
plus
incl. Guide System Insertion post and
cover screw, sterile
Material
Titanium Grade 4
K1053.3311
3.3 mm
11 mm
2.7 mm
K1053.3313
13 mm
K1053.3316
16 mm
K1053.3809
3.8 mm
9 mm
3.5 mm
K1053.3811
11 mm
K1053.3813
13 mm
K1053.3816
16 mm
K1053.4309
4.3 mm
9 mm
3.9 mm
K1053.4311
11 mm
K1053.4313
13 mm
K1053.4316
16 mm
Guide System Pilot drill set
internal irrigation, sterile
(for pilot drilling Ø 2.0 mm)
Material
Stainless steel
J5043.3311
3.3 mm
11 mm
(incl. 5 and
9 mm)**
-
J5043.3313
13 mm
(incl. 5, 9 and
11 mm)**
J5044.3316*
16 mm
J5043.4309
3.8 mm
9 mm
(incl. 5
mm)**
4.3 mm
J5043.4311
3.8 mm
11 mm
(incl. 5 and
9 mm)**
4.3 mm
J5043.4313
3.8 mm
13 mm
(incl. 5, 9 and
11 mm)**
4.3 mm
J5044.4316*
3.8 mm
16 mm
4.3 mm
* Necessary Guide System pilot drill for implant length 16 mm, following obligatory prior use of the pilot drill set length 13 mm.
**All Guide System pilot drill sets include a 5 mm long pilot drill, as well as all pilot drills necessary for the selected implant length.
All Guide System drills and gingiva punches are intended for single use only.
0.4 mm
L
A
