CAMLOG Vario SR Prosthetics Components

CAMLOG ® VARIO SR PROSTHETIC COMPONENTS CAMLOG ® VARIO SR ABUTMENTS CAMLOG ® Vario SR abutments are available in various gingival heights (GH) and in implant diameters 3.8/4.3/5.0/6.0 mm. They are color-coded by implant diameter. Straight CAMLOG ® Vario SR abutments are delivered with an CAMLOG ® Vario SR abutment screw (Art. No. J4007.1600, M1.6 for Ø 3.8/4.3 mm; Art. No. J4007.2000, M2.0 for Ø 5.0/6.0 mm). Angled CAMLOG ® Vario SR abutments each include a CAMLOG ® abutment screw (Art. No. J4005.1601, M1.6 for Ø 3.8/4.3 mm; Art. No. J4005.2001, M2.0 for Ø 5.0/6.0 mm). Ø: Implant diameter GH: Gingival height PH: Prosthetic height (measured from the abutment shoulder to occlusal abutment edge) All CAMLOG ® Vario SR abutments incl. the enclosed abutment screws are packed sterile. NOTE Only Vario SR prosthetic components may be used in combination (exception: angled CAMLOG ® Vario SR abutments 20°/30° with CAMLOG ® abutment screws Art. No. J4005.1601/2001). GH: Gingival height PH: Prosthetic height PH PH PH GH GH GH GH GH CAMLOG ® VARIO SR ABUTMENTS, STRAIGHT, incl. CAMLOG ® Vario SR abutment screw Art. No. K2560.3808 K2560.4308 K2560.5008 K2560.6008 Ø mm 3.8 4.3 5.0 6.0 GH mm 0.8 0.8 0.8 0.8 PH mm 3.8 3.8 3.8 3.8 CAMLOG ® VARIO SR ABUTMENTS, ANGLED, incl. CAMLOG ® abutment screw Art. No. K2561.3800 K2561.4300 K2561.5000 K2561.6000 K2562.3800 K2562.4300 K2562.5000 K2562.6000 Ø mm 3.8 4.3 5.0 6.0 3.8 4.3 5.0 6.0 Angle 20° 20° 20° 20° 30° 30° 30° 30° GH mm 3.1–1.8 3.2–1.7 3.9–2.2 4.0–2.0 3.1–1.2 3.2–1.0 4.0–1.5 4.3–1.3 PH mm 3.8 3.8 3.8 3.8 3.8 3.8 3.8 3.8
