Titanium Bases CAD/CAM Crown and Bridge Restorations

3 TITANIUM BASES CAD/CAM FOR CROWN AND BRIDGE RESTORATIONS CAMLOG ® UND CONELOG ® TITANIUM BASES CAD/CAM PRODUCT DESCRIPTION CAMLOG ® and CONELOG ® Titanium bases CAD/CAM are acting as bonding bases for customized, implant-supported dental restorations made of suita- ble materials. Suitable dental scanners can be used to visually record the titanium base CAD/CAM, third-party scan abutments matched to the tita- nium base, and the scanbodies. Then the obtained digitally acquired geometry is used in the modeling and fabrication of meso and superstruc- tures using CAD/CAM techniques. CAMLOG ® TITANIUM BASE CAD/CAM CROWN AND BRIDGE VERSIONS CAMLOG ® Titanium bases CAD/CAM are available in crown and bridge versions and are supplied non-sterile, each with an abutment screw and a bonding aid. CROWN RESTORATIONS The CAMLOG ® Titanium bases CAD/CAM with Tube-in-Tube ® Implant-abut- ment connection for positioning/as antirotational mechanism are available for crown restorations. Titanium bases for crowns are color-coded to match the implant diameter and are available for all CAMLOG ® Implant diameters with a shoulder height of 0.3 mm. For 3.3 mm implant diameters the shoulder height is 0.4 mm. Single crown restorations are secured against rotating with a rotation-lock- ing cam. NOTE These abutments are not suitable for primary splinting. Prosthetic height Rotation- locking cam Shoulder height CAMLOG ® Titanium bases CAD/CAM crown and bridge CAMLOG ® Abutment screws, thread M 1.6 and M 2.0 CAMLOG ® Titanium base CAD/CAM, crown, with Tube-in-Tube ® Implant-abutment connection, titanium alloy, incl. CAMLOG ® Abutment screw and white bonding aid (POM) ART. NO. K2244.3348 K2244.3848 K2244.4348 K2244.5048 K2244.6048 Implant Ø in mm 3.3 3.8 4.3 5.0 6.0 Shoulder height in mm 0.4 0.3 0.3 0.3 0.3 Prosthetic height in mm 5.1 5.0 5.0 5.0 5.0
